Visaton F 8 SC - 8 Ohm
Magnetically shielded 8 cm (3.3") broadband loudspeaker
Visaton F 8 SC - 8 Ohm
Magnetically shielded 8 cm (3.3") broadband loudspeaker
€13.65
Our previous price
€19.50
Save 30%
Tax included
Shipping excluded
4-0008
Secure delivery
Delivery by DHL in a well-padded shipping box
Return policy
14-day right of return
Magnetically shielded 8 cm (3.3") broadband loudspeaker with balanced frequency response.
Especially suitable for small multi-media boxes.
Very good value for money.
Applications
- Multi-media boxes
- Video monitors
- TV sets
- Computer terminals
Â
Characteristics
- moisture-impregnated membrane
- Metal design
- magnetic shielding
Â
Technical data
| Rated load capacity | 20 W |
|---|---|
| Music loading | 30 W |
| Nominal impedance Z | 8 Ohm |
| Transmission range (-10 dB) | 80–15000 Hz |
| Medium sound pressure level | 82 dB (1 W/1 m) |
| Beam angle (-6 dB) | 180°/4000 Hz |
| Border deflection | +/-2.5 mm |
| Reaction frequency fs | 125 Hz |
| Magnetic induction | 0,8 T |
| Magnetic flux | 150 μWb |
| Upper pole plate height | 3 mm |
| Oscillating coil diameter | 20 mm |
| Winding height | 4.5 mm |
| Sound wall opening | 76 mm |
| Weight net | 0,25 % |
| DC resistance Rdc | 7.9 Ohm |
| Mechanical Q-factor Qms | 2,94 |
| Electric Q-factor Qes | 1,29 |
| Total Q factor Qts | 0,9 |
| Equivalent air yield volume Vas | 1.0 l |
| Effective membrane surface Sd | 30 cm2 |
| Dynamic moving mass Mms | 2 g |
| Drive factor Bxl | 2,2 Tm |
| Vibration coil inductance L | 0,3 mH |
| Temperature range | −25 ... 70 °C |
