Visaton TL 16 H - 8 Ohm High-End Tonhorn
High-end high-tone horn
Visaton TL 16 H - 8 Ohm High-End Tonhorn
High-end high-tone horn
€272.15
Our previous price
€388.78
Save 30%
Tax included
Shipping excluded
4-0144
Secure delivery
Delivery by DHL in a well-padded shipping box
Return policy
14-day right of return
High-end high-tone horn for the high tone range from 5000 Hz.
The extremely light diaphragm of a titanium aluminum alloy has a very linear frequency response in addition to an extremely dynamic pulse behavior.
The powerful strontium ferrite magnet together with the 16 mm coil guarantees an enormous efficiency.
Technical data
| Nominal load capacity with high-pass filter | 150 W (12 dB/oct; 7500 Hz) |
|---|---|
| Music loadability with high-pass filter | 200 W (12 dB/oct; 7500 Hz) |
| Nominal impedance Z | 8 Ohm |
| Transmission range (-10 dB) | 2200–35000 Hz |
| Medium sound pressure level | 100 dB (1 W/1 m) |
| Beam angle (-6 dB) | 67°/8000 Hz |
| Reaction frequency fs | 6000 Hz |
| Magnetic induction | 1.6 |
| Magnetic flux | 200 μWb |
| Upper pole plate height | 2,5 mm |
| Oscillating coil diameter | 16 mm |
| Weight net | 1,3 kg |
| DC resistance Rdc | 6.9 Ohm |
| Vibration coil inductance L | 0,17 mH |
4-0144
