BPA CerAl 4-W69 home cinema housing kit
Set price!
BPA CerAl 4-W69 home cinema housing kit
Set price!
€492.00
Tax included
Shipping excluded
Delivery time: 2-3 weeks
2-0317 MDF-roh, Stoß, BS
Secure delivery
Delivery by DHL in a well-padded shipping box
Return policy
14-day right of return
Housing kit for Blue Planet Acoustic CerAl 4-W69 home cinema:
The article contains the following wood parts:
| Parts | Dimensions (mm) | Number |
| Front loudspeaker CerAl 4.2 | ||
| Material: 16 mm MDF raw or black or 15 mm MPX Birch bright | ||
| Front | 160 x 420 | 2 |
| Rear wall | 160 x 420 | 2 |
| Cover and bottom | 128 x 238 | 4 |
| Side walls | 238 x 420 | 4 |
| Material: 10 mm MDF raw or black or 12 mm MPX birch bright | ||
| FR | 65 x 128 | 2 |
| Transparency | 244 x 128 | 2 |
| Parts | Dimensions (mm) | Number |
| Center Speakers CerAl 4.2 Center | ||
| Material: 16 mm MDF raw or black or 15 mm MPX Birch bright | ||
| Front | 160 x 420 | 1 |
| Rear wall | 160 x 420 | 1 |
| Cover and bottom | 128 x 238 | 2 |
| Side walls | 238 x 420 | 2 |
| Material: 10 mm MDF raw or black or 12 mm MPX birch bright | ||
| FR | 65 x 128 | 1 |
| Transparency | 244 x 128 | 1 |
| Parts | Dimensions (mm) | Number |
| Rear Speaker CerAl 4.1 | ||
| Material: 16 mm MDF raw or black or 15 mm MPX Birch bright | ||
| Front | 160 x 270 | 2 |
| Rear wall | 160 x 270 | 2 |
| Cover and bottom | 128 x 188 | 4 |
| Side walls | 188 x 270 | 4 |
| Parts | Dimensions (mm) | Number |
| Subwoofer Sub-W69 | ||
| Material: 22 mm MDF raw or 25 mm MDF black or 21 mm MPX birch bright | ||
| Front | 240 x 500 | 2 |
| Rear wall | 240 x 500 | 2 |
| Cover and bottom | 196 x 356 | 4 |
| Side walls | 356 x 500 | 4 |
| Base | 240 x 400 | 2 |
| Material: 10 mm MDF raw | ||
| Distance | 196 x 356 | 2 |
All parts with milling / cutouts according to the construction plan of BPA.
No speakers included, only wooden parts.
CNC-milled sound walls and housing from the professional
The latest 5-axis technology for perfect results.
A different idea ?
Ask us !
Assembly of housing kits
We are always asked, "Can I do this with the assembly?"
Our answer is clear: YES!
All our kits are dimensionally CNC-freezed.
From a material thickness of 15mm, we basically use flat dowels for easy assembly.
The flat dowel system consists of the Lamellos and the necessary slots.
The slots are no longer visible after assembly.
The Lamellos supplied are simply inserted with some glue into the slots provided for this purpose.
As a result, the housing parts can be simply plugged together.
This ensures that all parts are in the right position.
Please make sure to use sufficient glue and suitable screw clamps.
For unskilled “housing builders” we recommend to put the housing parts together first without glue to get an impression of the procedure.
All these points provide a perfect result, with minimal effort.
2-0317 MDF-roh, Stoß, BS
