Visaton WS 25 E - 8 Ohm bass driver
25 cm (10") tweeter
Visaton WS 25 E - 8 Ohm bass driver
25 cm (10") tweeter
€40.61
Our previous price
€58.02
Save 30%
Tax included
Shipping excluded
4-0119
Secure delivery
Delivery by DHL in a well-padded shipping box
Return policy
14-day right of return
25 cm (10") tweeter with coated paper membrane, inverse dust-protection cup, rubber bead and deep-drawn pole plate for large membrane bead.
Due to the special basket shape especially suitable as replacement fitting for many hi-fi finish boxes.
Technical data
| Rated load capacity | 80 W |
|---|---|
| Music loading | 110 W |
| Nominal impedance Z | 8 Ohm |
| Transmission range (-10 dB) | fu–6000 Hz |
| (fu: lower limit frequency depending on the housing) | . |
| Medium sound pressure level | 88 dB (1 W/1 m) |
| Border deflection | +/-6 mm |
| Reaction frequency fs | 34 Hz |
| Magnetic induction | 1.0 |
| Magnetic flux | 310 μWb |
| Upper pole plate height | 4 mm |
| Oscillating coil diameter | 25 mm |
| Winding height | 15 mm |
| Sound wall opening | 225 mm |
| Weight net | 1,25 kg |
| DC resistance Rdc | 5,9 Ohm |
| Mechanical Q-factor Qms | 2,82 |
| Electric Q-factor Qes | 2,92 |
| Total Q factor Qts | 1,43 |
| Equivalent air yield volume Vas | 113 l |
| Effective membrane surface Sd | 346 cm2 |
| Dynamic moving mass Mms | 33 g |
| Drive factor Bxl | 3.8 T m |
| Vibration coil inductance L | 0,8 mH |
| Connections | 5,2 x 0.8 mm (+) 2,8 x 0.8 mm (−) |
