Visaton SC 13 - 8 Ohm HiFi broadband loudspeaker

Magnetic shielded 13 cm (5") HiFi broadband loudspeaker

€30.48
Our previous price €43.54
Save 30%
Tax included Shipping excluded
Breeding bands
4-0076
Quantity
Wishlist
Compare
available at manufacturer
  Secure delivery

Delivery by DHL in a well-padded shipping box

  Return policy

14-day right of return

Magnetic shielded 13 cm (5") HiFi broadband loudspeaker with cellulose membrane and rubber beads.

Also usable as low-medium toner.

Thanks to very balanced frequency response and good efficiency together with the shielded high-tone SC 10 N - 8 Ohm especially suitable in magnetically shielded 2-way combinations for surround center loudspeakers and multi-media boxes.

Applications

- surround center speakers

- Multi-media boxes

- Video monitors

- TV sets

- Computer terminals

Case recommendations

Volume/principle fc)/QTC
10 l/closed 103 Hz/0.94
20 l/closed 91 Hz/0.83

Technical data

Rated load capacity 40 W
Music loading 60 W
Nominal impedance Z 8 Ohm
Transmission range (-10 dB) fu–13000 Hz
(fu: lower limit frequency depending on the housing) .
Medium sound pressure level 90 dB (1 W/1 m)
Beam angle (-6 dB) 58°/4000 Hz
Border deflection +/-7,5 mm
Reaction frequency fs 78 Hz
Magnetic induction 1 T
Magnetic flux 250 μWb
Upper pole plate height 4 mm
Oscillating coil diameter 20 mm
Winding height 5.5 mm
Sound wall opening 113 mm
Weight net 0,62
DC resistance Rdc 7.2 Ohm
Mechanical Q-factor Qms 2,95
Electric Q-factor Qes 0,94
Total Q factor Qts 0,71
Equivalent air yield volume Vas 7,4 l
Effective membrane surface Sd 79 cm2
Dynamic moving mass Mms 4.8 g
Drive factor Bxl 4,2 T m
Vibration coil inductance L 0,7 mH
Temperature range −25 ... 70 °C
