Visaton K 40 - 50 Ohm Visaton K 40 - 50 Ohm Visaton K 40 - 50 Ohm Visaton K 40 - 50 Ohm
Visaton K 40 - 50 Ohm
Visaton K 40 - 50 Ohm
Visaton K 40 - 50 Ohm
Visaton K 40 - 50 Ohm

Visaton K 40 - 50 Ohm

4 cm (1.6") small speaker

€4.89
Our previous price €6.99
Save 30%
Tax included Shipping excluded
Small speaker
4-0172
Quantity
Wishlist
Compare
available at manufacturer
  Secure delivery

Delivery by DHL in a well-padded shipping box

  Return policy

14-day right of return

4 cm (1.6") small speaker with plastic membrane (Mylar) and metal basket.

Extremely small size, therefore well suited for signal output in devices and installations where little space is available.

Applications

- voice and signal output in internal and external devices

Technical data

Rated load capacity 1 W
Music loading 2 W
Nominal impedance Z 50 Ohm
Transmission range (-10 dB) 350–6000 Hz
Medium sound pressure level 83 dB (1 W/1 m)
Reaction frequency fs 520 Hz
Oscillating coil diameter 13.5 mm
Winding height 1.8 mm
Sound wall opening 36.5 mm
Weight net 0,01 kg
Protection class IP 65 *)
Temperature range −40 – 70 °C
