Visaton R 10 SC Special - 8 Ohm broadband speakers
Magnetically shielded 10 cm (4") broadband loudspeaker
Visaton R 10 SC Special - 8 Ohm broadband speakers
Magnetically shielded 10 cm (4") broadband loudspeaker
€11.01
Our previous price
€15.73
Save 30%
Tax included
Shipping excluded
4-0074
Secure delivery
Delivery by DHL in a well-padded shipping box
Return policy
14-day right of return
Magnetically shielded 10 cm (4") broadband loudspeaker with high efficiency and balanced frequency response with high tone increase.
This makes very good speech comprehensibility. Water-repellent membrane.
Particularly suitable as a control loudspeaker for electronic devices and as a built-in loudspeaker for public transport and facilities.
It corresponds to the model R 10 SC - 8 Ohm, but with connecting lugs 6.3 x 0.8 mm (+) and 4,8 x 0.8 mm (-) and with impregnated paper seal.
Applications
- Video monitors
- Control loudspeaker for electronic devices
- Ceiling loudspeakers in rail vehicles and buses
Characteristics
- working in cold according to EN 60068-2-1/EN 50155
- Storage up to -40 °C according to EN 60068-2-1/EN 50155
- working with moist heat (cyclic) according to EN 60068-2-3/EN 50155
- working in dry heat according to EN 60068-2-2/EN 50155
Technical data
| Rated load capacity | 20 W |
|---|---|
| Music loading | 30 W |
| Nominal impedance Z | 8 Ohm |
| Transmission range (-10 dB) | 100–13000 Hz |
| Medium sound pressure level | 90 dB (1 W/1 m) |
| Beam angle (-6 dB) | 92°/4000 Hz |
| Border deflection | +/-1.5 mm |
| Reaction frequency fs | 165 Hz |
| Magnetic induction | 0,95 |
| Magnetic flux | 135 μWb |
| Upper pole plate height | 3 mm |
| Oscillating coil diameter | 15 mm |
| Winding height | 4 m |
| Sound wall opening | 93 m |
| Weight net | 0,24 |
| DC resistance Rdc | 7.4 Ohm |
| Mechanical Q-factor Qms | 5,3 |
| Electric Q-factor Qes | 2,63 |
| Total Q factor Qts | 1,76 |
| Equivalent air yield volume Vas | 2.3 l |
| Effective membrane surface Sd | 56 cm2 |
| Dynamic moving mass Mms | 2,2 g |
| Drive factor Bxl | 2.4 t m |
| Vibration coil inductance L | 0,5 mH |
| Connections | 6.3 x 0.8 mm (+) 4.8 x 0.8 mm (−) |
| Temperature range | −40 – 70 °C |
